PRIUS BEARINGS · SLEWING RING BEARING

ROD01400
slewing ring bearing

ROD01400 is listed as a Liebherr catalogue cross-reference for a PRIUS slewing ring alternative. The catalogue envelope is outside diameter 1635.2 mm, inside diameter 1253 mm, height 132 mm. Send the complete model suffix, mounting details and operating loads for review.

Request a quote →Browse all models ↗
PRIUS alternative supply2D section referenceRFQ engineering review

DIMENSIONAL REFERENCE

MODEL ROD01400
Liebherr catalogue section reference for ROD01400

Catalogue illustrations may cover a bearing series. Confirm the exact model, suffix, dimensions and hole pattern against the final drawing before selection.

ENGINEERING DATA

ROD01400
parameters

Catalogue reference dimensions and load information for preliminary selection. Confirm the final PRIUS drawing and ratings before ordering.

ModelROD01400
Brand / alternativePRIUS BEARINGS · Alternative for Liebherr
TypeSlewing ring bearing
Weight (kg)646 kg
Outside diameter Da (mm)1,635.2 mm
Inside diameter di (mm)1,253 mm
Ring height H (mm)132 mm
Outer reference ØO (mm)1,432 mm
Inner reference ØU (mm)1,430 mm
Outer ring height H1 (mm)106 mm
Inner ring height H2 (mm)123 mm
Outer mounting length La (mm)1,505 mm
Inner mounting length Li (mm)1,305 mm
Mounting hole count36
Mounting hole diameter (mm)24 mm
Hole pitch diameter d (mm)1,596 mm
Gear module14
Gear tooth count114
Tooth correction7
Gear tip reduction k·m (mm)-1.4
Tooth width b (mm)106 mm
Tooth force, standard (kN)136.2 kN
Tooth force, maximum (kN)272.4 kN
Basic static axial load rating C0a (kN)10,375 kN
Basic dynamic axial load rating Ca (kN)1,308 kN
Bearing typeROD 21 DA external gear
Confirm dimensions & request a quote →

NEED A MATCH?

Send us your
drawing or load case.

We can review the mounting envelope, load requirements and delivery target for a PRIUS BEARINGS slewing ring alternative.

Start an enquiry →

MODEL SELECTION

Related slewing
ring bearings

Compare references from the same brand catalogue, prioritising the same family and arrangement, then nearby available envelope dimensions. Related references are not confirmed interchangeable.

Liebherr · Slewing ring bearingKUD01506outside diameter 1617 mm, inside diameter 1334.4 mm, height 123 mm →Liebherr · Slewing ring bearingKUD01440outside diameter 1653.6 mm, inside diameter 1320 mm, height 120 mm →Liebherr · Slewing ring bearingKUD01497outside diameter 1665.6 mm, inside diameter 1383 mm, height 123 mm →Liebherr · Slewing ring bearingROD01600outside diameter 1831.2 mm, inside diameter 1402 mm, height 132 mm →

FREQUENT QUESTIONS

Can PRIUS review an alternative for ROD01400?

We review the model, dimensions, load case, mounting arrangement and quantity before confirming a quotation.

What information is needed for selection?

For ROD01400, provide the complete reference and suffix, confirm outside diameter 1635.2 mm, inside diameter 1253 mm, height 132 mm, and include gear configuration, mounting-hole details, loads and operating speed.

Can you check an alternative from a drawing or sample?

Yes. Email the drawing, catalogue page or clear photos to sales@priusbearing.com. Our team can review the fit before quotation.
