Thin Section Bearings/20 mm Series/K02520CP0

20 mm Series · Type C · Open · Radial contact

K02520CP0
thin section bearing

Metric heavy-section radial contact bearing for demanding radial loads.

Request a quote →Back to all models
PRIUS BEARINGS K02520CP0 open thin section bearingOPEN / K02520CP0
PRIUS BEARINGSMECHANICAL DRAWING · K02520CP0UNITS: mm · SCALE: NTS
PRIUS BEARINGS K02520CP0 dimensioned mechanical drawing
PART NUMBERK02520CP0
BORE / d25 mm
O.D. / D65 mm
WIDTH / B20 mm
L1 / L2 / L340 mm / 50 mm / —
TYPEType C · Open · Radial contact
DYNAMIC RADIAL LOAD11552 N
STATIC RADIAL LOAD9983 N
DYNAMIC THRUST LOADN/A
STATIC THRUST LOADN/A
WEIGHT0.34 kg

TECHNICAL DATA

Specification
at a glance.

Bore25 mm
Outside diameter65 mm
Radial section20 mm
L1 land diameter40 mm
L2 land diameter50 mm
L3 counterbore—
Dynamic radial capacity11552 N
Dynamic thrust capacityN/A
Static radial capacity9983 N
Static thrust capacityN/A
MaterialAISI 52100 steel
SeparatorType A circular pocket
PrecisionKaydon Precision Class 1 / ABEC-1F or better
Temperature range-54°C to +121°C
Weight0.34 kg
