Slewing Rings/SKF references/RKS.061.20.0544← View all models

PRIUS BEARINGS · SLEWING RING BEARING

RKS.061.20.0544
slewing ring bearing

RKS.061.20.0544 is listed as a SKF catalogue cross-reference for a PRIUS slewing ring alternative. The catalogue envelope is outside diameter 640.8 mm, inside diameter 472 mm, height 56 mm. Send the complete model suffix, mounting details and operating loads for review.

Request a quote →Browse all models ↗
PRIUS alternative supply2D section referenceRFQ engineering review
PRIUS BEARINGS RKS.061.20.0544 external gear slewing ring bearingEXTERNAL GEAR / RKS.061.20.0544

DIMENSIONAL REFERENCE

MODEL RKS.061.20.0544
SKF RKS.061.20.0544 catalogue drawing reference

Catalogue illustrations may cover a bearing series. Confirm the exact model, suffix, dimensions and hole pattern against the final drawing before selection.

ENGINEERING DATA

RKS.061.20.0544
parameters

Catalogue reference dimensions and load information for preliminary selection. Confirm the final PRIUS drawing and ratings before ordering.

ModelRKS.061.20.0544
Brand / alternativePRIUS BEARINGS · Alternative for SKF
TypeSKF Single-row ball · External gear
Outside diameter Da (mm)640.8
Inside diameter di (mm)472
Ring height H (mm)56
Mounting hole count32
Mounting hole diameter (mm)13.5
Inner ring reference Ji (mm)498
Inner ring hole diameter Ki (mm)13.5
Inner ring hole count Ni32
Outer ring reference Je (mm)590
Outer ring hole diameter Ke (mm)12
Outer ring hole count Ne28
Confirm dimensions & request a quote →

NEED A MATCH?

Send us your
drawing or load case.

We can review the mounting envelope, load requirements and delivery target for a PRIUS BEARINGS slewing ring alternative.

Start an enquiry →

MODEL SELECTION

Related slewing
ring bearings

Compare references from the same brand catalogue, prioritising the same family and arrangement, then nearby available envelope dimensions. Related references are not confirmed interchangeable.

SKF · SKF Single-row ball · External gearRKS.061.20.0644outside diameter 742.8 mm, inside diameter 572 mm, height 56 mm →SKF · SKF Single-row ball · External gearRKS.061.20.0414outside diameter 504 mm, inside diameter 342 mm, height 56 mm →SKF · SKF Single-row ball · External gearRKS.061.20.0744outside diameter 838.8 mm, inside diameter 672 mm, height 56 mm →SKF · SKF Single-row ball · External gearRKS.061.20.0844outside diameter 950.4 mm, inside diameter 772 mm, height 56 mm →

FREQUENT QUESTIONS

Can PRIUS review an alternative for RKS.061.20.0544?

We review the model, dimensions, load case, mounting arrangement and quantity before confirming a quotation.

What information is needed for selection?

For RKS.061.20.0544, provide the complete reference and suffix, confirm outside diameter 640.8 mm, inside diameter 472 mm, height 56 mm, and include gear configuration, mounting-hole details, loads and operating speed.

Can you check an alternative from a drawing or sample?

Yes. Email the drawing, catalogue page or clear photos to sales@priusbearing.com. Our team can review the fit before quotation.
