Slewing Rings/SKF references/RKS.060.20.0844← View all models

PRIUS BEARINGS · SLEWING RING BEARING

RKS.060.20.0844
slewing ring bearing

RKS.060.20.0844 is listed as a SKF catalogue cross-reference for a PRIUS slewing ring alternative. The catalogue envelope is outside diameter 916 mm, inside diameter 772 mm, height 56 mm. Send the complete model suffix, mounting details and operating loads for review.

Request a quote →Browse all models ↗
PRIUS alternative supply2D section referenceRFQ engineering review

DIMENSIONAL REFERENCE

MODEL RKS.060.20.0844
SKF RKS.060.20.0844 catalogue drawing reference

Catalogue illustrations may cover a bearing series. Confirm the exact model, suffix, dimensions and hole pattern against the final drawing before selection.

ENGINEERING DATA

RKS.060.20.0844
parameters

Catalogue reference dimensions and load information for preliminary selection. Confirm the final PRIUS drawing and ratings before ordering.

ModelRKS.060.20.0844
Brand / alternativePRIUS BEARINGS · Alternative for SKF
TypeSKF Single-row ball · Gearless
Outside diameter Da (mm)916
Inside diameter di (mm)772
Ring height H (mm)56
Mounting hole count40
Mounting hole diameter (mm)13.5
Outer ring reference Je (mm)890
Outer ring hole diameter Ke (mm)12
Outer ring hole count Ne36
Inner ring reference Ji (mm)798
Inner ring hole diameter Ki (mm)13.5
Inner ring hole count Ni40
Confirm dimensions & request a quote →

NEED A MATCH?

Send us your
drawing or load case.

We can review the mounting envelope, load requirements and delivery target for a PRIUS BEARINGS slewing ring alternative.

Start an enquiry →

MODEL SELECTION

Related slewing
ring bearings

Compare references from the same brand catalogue, prioritising the same family and arrangement, then nearby available envelope dimensions. Related references are not confirmed interchangeable.

SKF · SKF Single-row ball · GearlessRKS.060.20.0944outside diameter 1016 mm, inside diameter 872 mm, height 56 mm →SKF · SKF Single-row ball · GearlessRKS.060.20.0744outside diameter 816 mm, inside diameter 672 mm, height 56 mm →SKF · SKF Single-row ball · GearlessRKS.060.20.1094outside diameter 1166 mm, inside diameter 1022 mm, height 56 mm →SKF · SKF Single-row ball · GearlessRKS.060.20.0644outside diameter 716 mm, inside diameter 572 mm, height 56 mm →

FREQUENT QUESTIONS

Can PRIUS review an alternative for RKS.060.20.0844?

We review the model, dimensions, load case, mounting arrangement and quantity before confirming a quotation.

What information is needed for selection?

For RKS.060.20.0844, provide the complete reference and suffix, confirm outside diameter 916 mm, inside diameter 772 mm, height 56 mm, and include gear configuration, mounting-hole details, loads and operating speed.

Can you check an alternative from a drawing or sample?

Yes. Email the drawing, catalogue page or clear photos to sales@priusbearing.com. Our team can review the fit before quotation.
